MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1- Cast Stove Top (076-201) +$432.72
QTY: 2- Cast Pedestal (076-211) +$101.47
QTY: 3- Surround Bottom (156-211) +$155.39
QTY: 4- Curved Door Assembly [No Glass] (156-513) +$643.64
QTY: 5- Thin Surround (156-261) +$104.40
QTY: 6- Side Shield [Black Set] (076-921) *No Longer Available* +$*0.00*
QTY: 6a- Side Shield [Stainless Set] (076-921) *No Longer Available* +$*0.00*
QTY: 7- Door Catch Assembly (156-519) +$107.34
QTY: 8- Heat Shield (076-516) +$Call to Order
QTY: 9- Door Hinge Assembly (156-523) +$116.14
QTY: 10- Ash drawer plug (942-110) +$43.86
QTY: 11- Ash Drawer Assembly (076-911) *No Longer Available* +$*0.00*
QTY: 12- Fan Opening Cover (076-004) +$46.79
QTY: 13- Back Shield (076-010) +$Call to Order
QTY: 14- Air tube (074-954) +$86.80
QTY: 15- Air Tube (033-953) +$68.26
QTY: 16- Baffle set (073-955) +$163.83
QTY: 17- Ashlip (076-913) *No Longer Available* +$*0.00*
QTY: 18- Smoke Deflector (820-483) +$80.93
QTY: 19- Neoceram Glass (940-366/P) +$308.92
QTY: 20- Manual (918-896) +$21.99
FAN ASSEMBLY
Item Description (Part Number)
QTY: 9- Fan Assembly Package (200-917) +$505.87
QTY: 1- Fan Housing Front (220-026) +$49.73
QTY: 2- Fan Housing Bottom (220-022) +$46.79
QTY: 3- Sensor Mount (220-036) +$13.10
QTY: 4- Fan Bracket Right Hand (200-227) +$16.18
QTY: 5- Fan Bracket Left Hand (200-228) +$16.18
QTY: 6- Fan Housing Back (200-229) +$46.79
QTY: 7- Fan [Motor only] (910-157/P) +$308.92
QTY: 8- Thermodisc (910-142) +$43.86
NOT SHOWN IN PICTURE
Item Description (Part Number)
QTY: 1- Bracket Catch (156-007) +$46.79
QTY: 2- Bracket Door Catch 4 Latch Door (156-028) +$26.20
QTY: 3- Rod Handle Mounting Chrome (156-029) +$43.86
QTY: 4- Latch Door Chrome Plate (156-532) +$77.99
QTY: 5- Door Support Hinge Bracket (156-021) +$32.36
QTY: 6- Door Catch Assembly (156-519) +$107.34
QTY: 7- Top Vent Grill (156-261) +$104.40
QTY: 8- Bottom Vent Grill (156-211) +$155.39
QTY: 9- Screw Set 1/4-20 x 3/16 Headless Slotted (904-840) +$10.95
QTY: 10- Draft Control Arm Chrome Plate 19 Ball Plunger Push Fit 0.312 x 0.643 in. (904-936) +$52.66
QTY: 11- Clevis Pin Stainless Steel with Retaining Ring 1/4x1 in. (904-937) +$43.86
QTY: 12- Bolt 1/4-20 - 5/16 x 3/8 Alloy Shoulder (904-939) +$16.18
QTY: 13- Bolt 1/4-20x1/2 Allen Head (904-753) +$10.95
QTY: 14- Bolt 10-24 x 1/2 Socket (904-779) +$10.95
QTY: 15- Fan Opening Cover (076-004) +$46.79
QTY: 16- Clip Fan [Each] (076-011) +$10.95
QTY: 17- Bracket Handle (076-019) +$10.95
QTY: 18- Cover Plate Air Kit (076-020) +$32.36
QTY: 19- Bracket Door Catch Righthand32 Cast Stove Top Cast (076-201) +$432.72
QTY: 20- Pedestal Cast Front [2 per unit, each sold separately] (076-211) +$101.47
QTY: 21- Bracket Vent Grill Top/Bottom [Each] (146-011) +$13.10
QTY: 22- Hinge Assembly Ash Drawer Door (156-526) +$68.26
QTY: 23- Round Magnet (904-790) +$10.95
QTY: 24- Cup Magnet 1/2 inch x 5/8 inch OD (904-791) +$10.95
QTY: 25- Screw 4-40 UNCx5/16in Flat Phil Machine (904-793) +$10.95
QTY: 26- Nut 4-40x3/16in.A/Fx3/32in.Th.Bras Plain (904-794) +$10.95
QTY: 27- Washer #4 External Star Flat Zinc Plt (904-795) +$10.95
QTY: 28- Instruction Manual (918-896) +$21.99
QTY: 29- Instruction Manual Complete Packaged (076-507) +$83.86
QTY: 30- Standard Firebrick - Box Of 20 Bricks (846-404) +$124.95
QTY: 31- Firebrick Set - Complete (076-960) +$133.75
QTY: 32- Ash Plug Handle (820-249) +$26.20
QTY: 33- Blower Motor Only With Squirrel Cage (910-157/P) +$308.92
QTY: 34- Ash Plug - Cast (942-110) +$43.86
QTY: 35- Bracket Door Catch (156-023) +$29.28
QTY: 36- Glass Retainer Clips/Screws [set of 2] (156-054) +$19.26
Item description (Part Number)
QTY: 37- Draft Control Arm Chrome Plate (156-060N) +$86.80
Item Description (Part Number)
QTY: 38- Draft Control Complete Assembly (156-521) +$222.92
QTY: 39- Handle Cast (156-241) +$49.73
QTY: 40- Door Latch Assembly (156-514) +$116.14
QTY: 41- Door Aligner Assembly Comes with Ball Plunger (156-515/P) +$104.40
QTY: 42- Draft Control Arm Chrome Plate (904-935) +$10.95
QTY: 43- Window Gasket [5 ft per package] (936-243-5) +$44.73
QTY: 44- Hinge Pin [2 per unit, each sold separately] [Hinge Pin Bolts sold separately, 4 required 904-513] (948-155) +$40.92
QTY: 44A- Hinge Pin Bolt [each sold separately] (904-513) +$10.95
QTY: 45- Bracket Door Catch Righthand (076-023) +$29.28
QTY: 46- Door Gasket with Gasket Adhesive Kit (846-570) +$107.34
QTY: 47- Glass Gasket [5 ft per package] (936-238-5) +$44.73
|
