MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1- FAN ACCESS PLATE (340-038) +$35.44
QTY: 2- GASKET - FAN ACCESS PLATE (340-103) +$13.10
QTY: 3- FAN ASSEMBLY [120 VOLTS] (320-517/P) +$236.98
QTY: 3A- FAN MOTOR [120 VOLTS] (910-331/P) +$180.71
QTY: 5- POWER CORD (910-750) +$43.86
QTY: 7- FAN AUTO ON/OFF THERMODISC (910-142) +$43.86
QTY: 8- THERMODISC BRACKET (NLA) *No Longer Available* +$*0.00*
QTY: 9- FAN SWITCH COVER (320-070) +$29.28
QTY: 13- BAFFLE PLATE (NLA) *No Longer Available* +$*0.00*
QTY: 17- WIRE HOLDER CLIP (NLA) *No Longer Available* +$*0.00*
QTY: 18- STRAIN RELIEF (NLA) *No Longer Available* +$*0.00*
QTY: 19- GROMMET FOR POWER CORD (NLA) *No Longer Available* +$*0.00*
QTY: 21- TOP FLUSH LOUVER (NLA) *No Longer Available* +$*0.00*
QTY: 23- BOTTOM FLUSH LOUVER (NLA) *No Longer Available* +$*0.00*
QTY: 33- BRICK PANEL - RIGHT (NLA) *No Longer Available* +$*0.00*
QTY: 34- BRICK PANEL - LEFT (NLA) *No Longer Available* +$*0.00*
QTY: 35- BRICK PANEL - BACK (NLA) *No Longer Available* +$*0.00*
QTY: 36- BRICK PANEL - TOP (NLA) *No Longer Available* +$*0.00*
QTY: 37- BRICK CLIP [2 per unit, each sold separately] (511-031) +$10.95
QTY: 38- BRICK FRONT TRIM (340-043) +$52.66
QTY: 44- GASKET VENT (340-099) +$43.86
ITEMS NOT SHOWN - MAIN ASSEMBLY
Item Description (Part Number)
QTY: 5A- WIRE FAN TO POWER CORD (910-692) +$10.95
QTY: 20- WIRE HARNESS [FACEPLATE] (910-752) +$40.92
QTY: 24- WIRE VALVE TO SPILL SWITCH (910-737) +$29.28
QTY: 21A- FLUSH LOUVER SET - BLACK/GOLD (340-924) +$Call to Order
QTY: 21B- FLUSH LOUVER SET - BLACK (340-922) +$Call to Order
QTY: 2C- FLUFH LOUVER SET - BLACK/STEEL (340-926) +$Call to Order
QTY: 31- BRICK PANEL SET - STANDARD BROWN (340-901) +$359.00
QTY: 31A- BRICK PANEL SET - STANDARD RED (340-902) +$359.00
QTY: 43- STOVE TOP (NLA) *No Longer Available* +$*0.00*
QTY: 45- BOTTOM CLIP [each] (340-094) +$16.18
QTY: 46- TOP BRACKET (340-043) +$52.66
QTY: 47- BASE BRICK PANEL [3 PIECES] (340-528) +$276.37
QTY: 48- INSTRUCTION MANUAL [hard copy] [918-408] (OMHC-R) +$9.99
QTY: 48A- INSTRUCTION MANUAL [electronic copy] [918-408] (OMEL-R) +$0.00
BURNER AND LOG ASSEMBLY
Item Description (Part Number)
QTY: 52- GASKET - VALVE TRAY (340-104) +$32.36
QTY: 56- PIEZO IGNITOR AND NUT (910-190) +$16.18
QTY: 57- SIT VALVE - NG (910-478) +$225.73
QTY: 57A- SIT VALVE - LP (910-478) +$225.73
QTY: 59- VALVE TRAY (NLA) *No Longer Available* +$*0.00*
QTY: 66- PILOT ASSEMBLY 3 FLAME SIT NG [recommend using High Temp Red Silicone and replacing gasket] (910-038/P) +$130.82
QTY: 66A- PILOT ASSEMBLY 3 FLAME SIT LP [recommend using High Temp Red Silicone and replacing gasket] ~Old Part #910-039~ (910-039/P) +$130.82
QTY: 66B- HIGH TEMPERATURE RED SILICONE (70AW) +$18.33
QTY: 67- ORIFICE #31 - NG (904-690) +$43.86
QTY: 67A- ORIFICE #50 - LP (904-641) +$43.86
QTY: 67B- ORIFICE GASKET (936-170) +$10.95
QTY: 68- PILOT ASSEMBLY GASKET (W840470) +$10.95
QTY: 79- BURNER ASSEMBLY - NG/LP (948-433) +$177.90
QTY: 82- BURNER GRATE ASSEMBLY (511-030) +$98.53
QTY: 91- LOG SET (340-930) +$628.43
ITEMS NOT SHOWN - BURNER AND LOG ASSEMBLY
Item Description (Part Number)
QTY: 57B- VALVE ASSEMBLY - NG (340-574/P) +$592.70
QTY: 57C- VALVE ASSEMBLY - LP (340-576/P) +$592.70
QTY: 60- PILOT ASSEMBLY 3 FLAME CONV - NG [recommend using High Temp Red Silicone and replacing gasket] (910-034) +$124.95
QTY: 61- REAR LOG TRAY (360-014) +$Call to Order
QTY: 91A- BOTTOM LOG (902-567) +$Call to Order
QTY: 91B- CENTER TOP LOG (902-568) +$Call to Order
QTY: 91C- FRONT LOG (902-569) +$Call to Order
QTY: 91E- LEFT LOG (902-570) +$Call to Order
QTY: 91F- RIGHT LOG (902-571) +$Call to Order
QTY: 91G- TOP LEFT LOG (902-572) +$Call to Order
QTY: 91H- REAR LOG (902-573) +$Call to Order
QTY: 91I- TOP RIGHT LOG (902-574) +$Call to Order
FULL SCREEN FRONT INSTALLATION
Item Description (Part Number)
QTY: 83- TOP FRAME (NLA) *No Longer Available* +$*0.00*
QTY: 84- FULL SCREEN DOOR - BLACK (340-910) +$Call to Order
QTY: 85- FULL SCREEN LEFT DOOR (NLA) *No Longer Available* +$*0.00*
QTY: 86- FULL SCREEN RIGHT DOOR (NLA) *No Longer Available* +$*0.00*
QTY: 87- BOTTOM FRAME (NLA) *No Longer Available* +$*0.00*
QTY: 88- SCREW #8 X 1/2 SELF TAPPING [4 per unit, each sold separately] (Call for Part #) +$Call to Order
QTY: 89- WIRE CLIP HOLDER [4 per unit, each sold separately] (910-199) +$10.95
QTY: 90- HINGE SPRING [2 per unit, each sold separately] (948-042) +$16.18
FACEPLATES, TRIMS AND HEARTHS
Item Description (Part Number)
QTY: 91- FACEPLATE SIDE - RIGHT (NLA) *No Longer Available* +$*0.00*
QTY: 92- FACEPLATE - TOP (NLA) *No Longer Available* +$*0.00*
QTY: 93- FACEPLATE SIDE - LEFT ASSEMBLY (NLA) *No Longer Available* +$*0.00*
QTY: 94- TRIM SIDE - RIGHT (NLA) *No Longer Available* +$*0.00*
QTY: 95- TRIM - TOP (NLA) *No Longer Available* +$*0.00*
QTY: 96- TRIM SIDE - LEFT ASSEMBLY (NLA) *No Longer Available* +$*0.00*
QTY: 97- BURNER ON/OFF SWITCH (910-246) +$29.28
QTY: 98- FAN SPEED CONTROL [120 VOLTS] (910-330) +$80.93
QTY: 98A- SPEED CONTROL KNOB C/W SPRING CLIP (904-586) +$16.18
QTY: 98B- FAN SPEED CONTROL KNOB (904-569) +$13.10
QTY: 99- FACEPLATE FILLER (NLA) *No Longer Available* +$*0.00*
QTY: 172- 1 INCH HEARTH TRIM (320-940) +$Call to Order
QTY: 176- 2 INCH HEARTH TRIM (320-942) +$65.00
QTY: 180- 4 INCH HEARTH TRIM (320-944) +$70.00
QTY: 184- 6 INCH HEARTH TRIM (320-946) +$Call to Order
QTY: 190- SCREW #8 X 1/2 INCH BLACK SELF-TAPPING [6 per unit, each sold separately] (Call for Part #) +$Call to Order
QTY: 191- SCREW #8 X 1/2 INCH BRASS PLATED SELF-TAPPING [2 per unit, each sold separately] (Call for Part #) +$Call to Order
QTY: 199- REGENCY LOGO ~Old Part # 948-216~ (948-223) +$10.95
ITEMS NOT SHOWN - FACEPLATES, TRIMS AND HEARTHS
Item Description (Part Number)
QTY: 200- COMPLETE FACEPLATES AND TRIM WITH BLACK TRIM (340-918) +$Call to Order
QTY: 201- OVERSIZED FACPLATE (340-919) +$Call to Order
QTY: 202- TRIM SET PACKAGED - BLACK (340-532) +$214.48
QTY: 203- OVERSIZED TRIM SET PACKAGED - BLACK (340-533) +$222.92
QTY: 204- TRIM SET PACKAGED - BRASS (340-950) +$Call to Order
QTY: 205- REMOTE CONTROL KIT [ON, OFF, THERMOSTAT] [INCLUDES: RECEIVER & REMOTE] (910-399) +$372.04
QTY: 206- NICKEL ACCENT SURROUND (790-938) +$96.54
|
